Operation
52
2. Press the power tilt switch āā (up) until
the outboard motor has tilted up com-
pletely.
3. Push the tilt support knob into the clamp
bracket to support the engine.
WARNING! After tilting the outboard
motor, be sure to support it with the
tilt support knob or tilt support lever.
Otherwise the outboard motor could
fall back down suddenly if oil in the
power trim and tilt unit or in the pow-
er tilt unit loses pressure.
[EWM00262]
NO-
TICE:
Do not use the tilt support lever
or knob when trailering the boat. The
outboard motor could shake loose
from the tilt support and fall. If the
motor cannot be trailered in the nor-
mal running position, use an addi-
tional support device to secure it in
the tilt position. For more detailed in-
formation, see page 57.
[ECM01641]
ZMU05533
N
ZMU05580
UP
UP
ZMU04900
