3-14
REMOTE CONTROL APPLICATIONS
6X7 REMOTE CONTROL DIMENSIONS
213 (8.39)
ECM bracket
116 (4.57)
M6 tapping mount screw
F
N
R
Throttle range
Throttle range
Shift
range
Shift
range
22.5
deg.
22.5
deg.
Max.
67 deg.
Max.
90 deg.
Template
* Wire-harness length:
approx. 2 m (6.5 ft)
170 (6.69)
130 (5.12)
155 (6.10)
59.5 (2.34)
16.5
(0.65)
40.5
(1.59)
43
(1.69)
56.5 (2.22) 6.4 (0.25)
35 (1.38)
38 (1.50)
54.4
(2.14)
Make three 7 mm (9/32 in) holes for mounting with bolts and nuts.
Drill 4 mm (5/32 in) holes for tapping screws, if the board is thicker
than 20 mm (0.79 in).
12.7
(0.50)
17.5
(0.69)
39.5
(1.56)
27 (1.06)
57
(2.24)
18
(0.71)
96.2
(3.79)
95 (3.74) 95 (3.74)
Mount board
mm (in.)
