Yamaha F20BE - Page 89

3-19
REMOTE SWITCH APPLICATIONS
INDEPENDENT SWITCH PANEL
IG SWITCH W/ PANEL
Ref. No. Part No. Description
1 64D-82570-03 With bullet connectors for stop switch
2 64D-82570-20 With 2-pin coupler for stop switch, For 6X3 and 6X7 RC
114 (4.49)
67.5 (2.66)9 (0.35)
63 (2.48)
63 (2.48)
47 (1.85)
47 (1.85)
P
R
B
G
Y
L
B
G
Y
R
Br
W
140 (5.51)
355 (13.98)
B
To stop S/W
W
54 (2.12)5.6 (0.22)
114 (4.49)
67.5 (2.66)
9 (0.35)
63 (2.48)
63 (2.48)
P
R
B
G
Y
L
B
G
Y
R
Br
W
140 (5.51)
355 (13.98)
B
W
47 (1.85)
47 (1.85)
54 (2.12)5.6 (0.22)
To stop S/W
1
2
mm (in.)
mm (in.)
