5-39
6R3-85721-30 (3 m)
-50 (5 m) -80 (8 m)
Fuel tank
OUT
IN
OUT
IN
(*1)
(*2)
6Y5-83553-M0 (2.5 m)
688-82520-00
6Y5-85752-02
Speed hose (* 1)
688-8258A-50 (5 m)
-60 (6 m)
6K1-8258A-40 (8 m) 61B-8258A-00 (9.5 m)
6Y5-83553-F1 (8 m)
6Y5-83553-20 (2.5 m)
(* 1) Select either speedometer or GPS (NMEA0183)
If GPS is connected, speed tube is not required.
(* 2) Water separator (Market obtainable)
68F-82553-50 (5 m)
-60 (6 m) -70 (7 m) -80 (8 m) -90 (9 m) -A0 (10.5 m)
GPS
Remote
Oil Tank
Remote
Oil Tank
TACH
FUEL
TACH
Engine
Oil Tank
Engine
Oil Tank
NMEA
0183
SPEED
6Y5-85721-F0
SPEED
6Y5-87112-S0
6Y5-8350T-03
(+)
WIRING DIAGRAMS
DIGITAL METER
TWIN-MOTOR W/ BINNACLE RC
L/250G
