WIRING DIAGRAMS
F200, F225, F250 w/ Variable Camshaft Timing
[Mechanical RC]
F250 [Digital Electronic Control]
F350, F300
Fuel hose
Gauge harness
Battery cable
Isolator cable (OP)
Throttle cable
Flushing hose (
Market
OP)
Shift cable
Speed tube
10-pin main harness
Coolant temp. lead and/or
Coolant press. tube (OP)
16-pin main harness
Flushing hose (
Market OP)
Fuel hose
Isolator cable (OP)
Battery cable (+) Battery cable (–)
16-pin main harness
Flushing hose (
Market
OP)
Isolator cable (OP)
Fuel hose
Speed tube (OP)
Battery cable
Bolt: 10 Nm, 1.0 kgf·m, 7.4 ft·lb
