Yamaha F30AET Rigging Guide

8-19
DIGITAL NETWORK GAUGE RIGGING KIT CONTENTS
ROUND STYLE GAUGE RIGGING KIT FOR EUROPE
SINGLE KIT 1 (TACH)
Kit P/N: 6YR-W0035-Y1
SINGLE KIT 1 (TACH) w/o Transom Wire Harness
Kit P/N: 6Y8-W0035-00
Part No. Part Name Q’ty Remarks
6Y8-82521-41 Pigtail bus wire, 9 ft 1
6Y8-82553-21 Main bus wire, 20 ft 1
6Y8-81920-11 Single-hub 1 With resistor
6Y8-82521-11 Pigtail bus wire, 2 ft 1
6Y8-81920-01 Multi-hub 1 With resistor cap, GRY
6Y8-82582-11 4-pin cap 2 For waterproof
6Y8-8350T-11 RND tachometer 1
6Y8-83553-01 PWR supply wire, 8 ft 1 With 10 amps fuse
Part No. Part Name Q’ty Remarks
6Y8-82521-11 Pigtail bus wire, 2 ft 1
6Y8-81920-01 Multi-hub 1 With resistor cap, GRY
6Y8-82582-11 4-pin cap, WHT 2 For waterproof
6Y8-8350T-11 RND tachometer 1
6Y8-83553-01 PWR supply wire, 8 ft 1 With 10 amps fuse

Yamaha F30AET Specifications

General

Engine Type	4-stroke
Displacement	747 cc
Max Output	30 hp
Starting System	Electric
SOHC	Yes
Cylinder	3
Full Throttle RPM Range	5000-6000 RPM
Ignition System	TCI
Lubrication	Wet Sump
Gear Shift	F-N-R
Fuel System	Electronic Fuel Injection (EFI)
Steering	Remote
Shaft Length	20 inches
Fuel Tank Capacity	N/A (External fuel tank)
Bore x Stroke	65.0 mm x 75.0 mm
