Yamaha F30B 2018 - Model Data: Electrical System and Fuel System

A-4
Model
F30BEHD
F30EHA
F30HA
F30BET
F30A
F40FED
F40FEHD
F40EHA
F40HA
F40FET
F40A
Battery cable length
1.64 m (5.4 ft)
(F30BEHD)
2.24 m (7.3 ft)
(F30EHA)
2.24 m (7.3 ft)
1.64 m (5.4 ft)
(F30BET)
2.24 m (7.3 ft) (F30A)
1.64 m (5.4 ft)
1.64 m (5.4 ft)
(F40FEHD)
2.24 m (7.3 ft)
(F40EHA)
2.24 m (7.3 ft)
1.64 m (5.4 ft)
(F40FET)
2.24 m (7.3 ft) (F40A)
Battery cable conductor
cross sectional area
15 mm² (AWG 5)
PTT system
Recommended fluid —
Yamalube Marine
Power Trim and Tilt
fluid or ATF Dexron II
ATF Dexron II
(F30BET)
Yamalube Marine
Power Trim and Tilt
fluid or ATF Dexron II
(F30A)
—
Yamalube Marine
Power Trim and Tilt
fluid or ATF Dexron II
ATF Dexron II
(F40FET)
Yamalube Marine
Power Trim and Tilt
fluid or ATF Dexron II
(F40A)
Electrical system technical data
Ignition timing control system
Spark plug
Spark plug gap 0.8–0.9 mm (0.031–0.035 in)
Cap resistance
5.0 k
Ignition coil
Primary coil resistance
0.180–0.240 
Secondary coil resis-
tance
3.26–4.88 k
Pulser coil
Air gap 0.35–1.35 mm (0.014–0.053 in)
Resistance
152.0–228.0 
Output peak voltage at
cranking (unloaded) (ref-
erence data)
5.0 V
Output peak voltage at
cranking (loaded) (refer-
ence data)
2.7 V
Output peak voltage at
cranking (loaded) (refer-
ence data)
6.5 V
Output peak voltage at
1500 r/min (loaded) (ref-
erence data)
9.8 V
