5-7
GB
EMU00884*
Emergency Starting Engine
1) Remove the top cowling.
2) Remove the start-in-gear protection
cable
1 and the choke cable 2 from
the holder on the starter.
After removing the choke cable, con-
firm that the cable end is contacted
with the silencer by pushing it inside.
3) Remove the start-in-gear protection
cable end by pulling it out from the
lever of the starter after loosening the
nut 3.
4) Remove the starter after removing
the three bolts.
q
w
5) Reinstall two bolts to secure the fuel
tank.
To Next Page
