2-5
GB
EMU00879¯
CHOKE KNOB
Pulling out this knob (setting it to ON)
supplies a rich mixture required to start
the engine.
EMU00059*
RECOIL STARTER HANDLE
(If equipped)
Pull the handle gently until resistance is
felt. Then vigorously pull the handle
straight out to crank the engine to start it.
q
we
EMU00062
TILLER HANDLE (for Tiller control
model)
Moving the tiller handle sideways to
adjust the steering direction. In addition,
this handle contains the functions as fol-
lows.
1 Throttle control grip
2 Throttle indicator
3 Throttle friction adjusting knob/screw
EMU00065
Throttle Control Grip
The throttle control grip is on the tiller
handle. Turn the grip counterclockwise to
increase speed and clockwise to decrease
speed.
