SPECIFICATIONS
Model
Unit F4AMH
Item
DIMENSIONS
Overall length mm (in.)
Overall width mm (in.)
Overall height S/L mm (in.)
Transom height S/L mm (in.)
Weight S/L kg (lb.)
PERFORMANCE
Full throttle operating range r/min
Maximum output kW @ r/min
Idling speed (in neutral) r/min
ENGINE
Type
Displacement cm
3
(cu.in.)
Bore
× stroke mm (in.)
Ignition system
Spark plug NGK
Spark plug gap mm (in.)
Control system
Starting system
Valve clearance (cold engine) IN mm (in.)
EX mm (in.)
Starting carburetion system
DRIVE UNIT
Gear positions
Gear ratio
Trim and tilt system
Propeller mark
FUEL AND OIL
Recommended fuel
Fuel tank capacity l (US gal, Imp gal)
Recommended engine oil
API
SAE
Engine oil capacity l (US qt, Imp qt)
Recommended gear oil
Gear oil capacity cm
3
(US oz, Imp oz)
TIGHTENING TORQUE
Spark plug N•m (kgf•m, lb•ft)
Engine oil drain bolt N•m (kgf•m, lb•ft)
717 (28.2)
361 (14.2)
1,029 (40.5)/1,156 (45.5)
435 (17.1)/562 (22.1)
22 (49)/23 (51)
4,000–5,000
2.9 @ 4,500
1,450–1,550
4-stroke, OHV, Single
112 (6.83)
59.0 × 41.0 (2.32 × 1.61)
TCI system
BR6HS
0.6–0.7 (0.024–0.028)
Tiller control
Manual start
0.08–0.12 (0.0031–0.0047)
0.08–0.12 (0.0031–0.0047)
Choke start
Forward-Neutral-Reverse
2.08 (27/13)
Manual tilt
BA
Regular unleaded gasoline
1.1 (0.29, 0.24)
4-stroke motor oil
SE, SF, SG, SH
10W-30, 10W-40
0.5 (0.53, 0.44)
Hypoid gear oil (SAE90)
100 (3.38, 3.52)
25 (2.5, 18)
20 (2.0, 15)
