Yamaha F40GET - Page 120

3-32
REMOTE SWITCH TYPES AND APPLICATIONS
ADAPTER FOR EMERGENCY STOP SWITCH LEAD
ENGINE SHUT-OFF LANYARD (CORD)
PTT SWITCH PANEL
Ref. No. Part No. Description
1 6X3-81971-00 2-pin coupler - bullet connector
2 6X3-81971-10 Bullet connector - 2-pin coupler
Part No. Description
682-82556-00
Part No. Description
688-82563-10 For PTT models
100 (3.94)
B
W
100 (3.94)
B
W
B
W
W
B
12
mm (in.)mm (in.)
1300 (51.2)
mm (in.)
G
R
L
960 (37.8)
10
(0.39)
19.2
(0.76)
TRIM & TILT
UP
DOWN
62 (2.44)
ON ON
(32 )
mm (in.)
