9-29
OTHER RIGGING KIT CONTENTS
LIGHTING COIL KIT (FOR EU, CA, JPN)
P/N: 6BX-W8130-A0
Applicable models:
Kit contents:
* For installation, see the service manual and/or service guide.
Global model F4B F5A F6C
US/CA Model F4A F6A
Part No. Part name Q’ty Remarks
6BX-81949-00 Wire lead 1
6BX-81960-00 Rectifier/ regulator 1
6BX-82388-00 Plate 1
6BX-82581-00 Stay 1
6BX-85510-A0 Stator ASSY 1
6BX-85550-A0 Rotor ASSY 1
90109-06M80 Bolt 1
90464-30009 Clamp 1
90465-08371 Clamp 1
97595-06516 Bolt 2
97595-06520 Bolt 3
