6-6
OPTIONAL EQUIPMENT
SPEED SENSOR KIT
Used to pick up the pitot tube pressure for water speed. For installation and connection, see the
instruction in the kit.
The speed sensor kit may be included in the rigging kit.
COOLANT PRESSURE SENSOR KIT
Used to pick up the coolant pressure of engine. For installation and connection, see the instruction
in the kit.
* For F350, factory-installed as standard.
Ref. No. Kit Part No. Remarks
1 60V-8A4L1-13 Fuel injected F30-F300 (V6), HPDI
2 6AW-8A4L1-01
F350, additional transom pitot tube (688-83556-01) and pressure tube
(688-83557-00) required.
Ref. No. Kit Part No. Remarks
1 60V-8A4L0-14 Fuel injected F30-F115, HPDI
2 69J-8A4L0-20 F200-F225 (3.3L)
3 63P-8A4L0-01 F150, F200 (2.8L), F200-F250 (3.3L-VCT), F225-F300 (4.2L)
