7-25
NETWORK WIRING DIAGRAMS
SINGLE STATION W/ 6Y8 GAUGE TWIN ENGINE APPLICATION
Ref.
No.
Part name Part No. Remarks
1 Main-harness (16P)
6X6-8258A-10 7 m (23 ft)
6X6-8258A-20 8 m (26 ft)
6X6-8258A-30 10 m (32 ft)
6X6-8258A-40 12 m (38 ft)
9 Fuel tank/GPS wire 6Y8-8356N-01 0.3 m (1 ft)
12 Main bus wire
6Y8-82553-01 0.3 m (1 ft)
6Y8-82553-50 3 m (10 ft)
6Y8-82553-11 4.5 m (15 ft)
6Y8-82553-21 6.1 m (20 ft)
6Y8-82553-31 7.6 m (25 ft)
6Y8-82553-41 9.1 m (30 ft)
13 Pigtail bus wire
6Y8-82521-01 0.3 m (1 ft)
6Y8-82521-11 0.6 m (2 ft)
6Y8-82521-21 0.9 m (3 ft)
6Y8-82521-31 1.8 m (6 ft)
6Y8-82521-41 2.7 m (9 ft)
6Y8-82521-51 3.6 m (12 ft)
15
Immobilizer PWR dis-
tribution wire
6Y8-81315-00 w/ 5-amp fuses, 2.4 m (8 ft)
16 Multi-hub 6Y8-81920-01 w/ resistor cap, Black
19 Transom multi-sensor 6Y8-83688-01
Depth, speed, water temp,
w/ 4.9 m (15 ft) wire
22 Immobilizer unit
6Y8-86254-02 EU
6Y8-86254-22 US, ANZ
6Y8-86254-30 JP
32
6X6 binnacle mount
Digital Electronic Con-
trol
6X6-48207-34 Single station
44 Main switch 6X6-82570-40 Main station helm
45 Start/stop button 6X6-82570-60 Main station helm
53 All start/stop button 6X6-82570-C0
For single/twin/triple engine
application
Ref.
No.
Part name Part No. Remarks
