Ref.
No.
Part name Part No. Remarks
1 Main-harness (16P)
6X6-8258A-10 7 m (23 ft)
6X6-8258A-20 8 m (26 ft)
6X6-8258A-30 10 m (32 ft)
6X6-8258A-40 12 m (38 ft)
9 Fuel tank/GPS wire 6Y8-8356N-01 0.3 m (1 ft)
12 Main bus wire
6Y8-82553-01 0.3 m (1 ft)
6Y8-82553-50 3 m (10 ft)
6Y8-82553-11 4.6 m (15 ft)
6Y8-82553-21 6.1 m (20 ft)
6Y8-82553-31 7.6 m (25 ft)
6Y8-82553-41 9.1 m (30 ft)
13 Pigtail bus wire
6Y8-82521-01 0.3 m (1 ft)
6Y8-82521-11 0.6 m (2 ft)
6Y8-82521-21 0.9 m (3 ft)
6Y8-82521-31 1.8 m (6 ft)
6Y8-82521-41 2.7 m (9 ft)
6Y8-82521-51 3.6 m (12 ft)
14
System power supply
wire
6Y8-83553-01 w/ 10-amp fuse, 2.4 m (8 ft)
16 Multi-hub 6Y8-81920-01 w/ resistor cap, Black
19 Transom multi-sensor 6Y8-83688-01
Depth, speed, water temp,
w/ 4.9 m (15 ft) wire
22 Immobilizer unit
6Y8-86254-02 EU
6Y8-86254-22 US, ANZ
6Y8-86254-30 JP
27
2nd helm harness
(2-12P)
6X6-8258A-B1 5 m (16 ft)
6X6-8258A-D1 8 m (26 ft)
6X6-8258A-F1 12 m (38 ft)
28
2nd helm harness
(3/4/6P)
6X6-8258A-G1 5 m (16 ft)
6X6-8258A-H1 8 m (26 ft)
6X6-8258A-J1 12 m (38 ft)
30
6X6 binnacle mount
Digital Electronic Con-
trol
6X6-48205-44 Dual station/Main station helm
31
6X6 binnacle mount
Digital Electronic Con-
trol
6X6-48205-53 Dual station/2nd station helm
40 Main switch 6X6-82570-31
6X6 binnacle mount Digital
Electronic Control, Main sta-
tion helm
41 Start/stop button 6X6-82570-80 2nd station helm
42 Engine shut-off switch 6X6-82570-90 2nd station helm
54 Station selector switch 6X6-82570-B0
For dual station, single/twin/
triple engine application
Ref.
No.
Part name Part No. Remarks
