1-20
OUTBOARD MOTOR DIMENSIONS
OVERALL DIMENSIONS (4-STROKE)
Global model
(US, CA model)
Symbol
F115AEHT
L1 mm (in) 662 (26.1)
L2 mm (in) —
L3 mm (in) —
L4 mm (in) 631 (24.8)
L5
S
mm (in)
—
L—
X 104 (4.1)
U—
L6
S
mm (in)
—
L—
X 1122 (44.2)
U—
L7 mm (in) 555 (21.9)
L8 mm (in) —
L9
S
mm (in)
—
L—
X16 (0.6)
U—
L10 mm (in) 75 (3.0)
H1
S
mm (in)
—
L—
X 1056 (41.6)
U—
H2 mm (in) 681 (26.8)
H3 mm (in) 191 (7.5)
H4
S
mm (in)
—
L—
X 643 (25.3)
U—
H5 mm (in) —
H6
S
mm (in)
—
L—
X 850 (33.5)
U—
H7 mm (in) 404 (15.9)
H8 mm (in) —
H9 mm (in) 879 (34.6)
H10 mm (in) 45 (1.8)
H11
S
mm (in)
—
L—
X14 (0.6)
U—
W1 mm (in) 246 (9.7)
W2 mm (in) —
W3 mm (in) —
W4 mm (in) —
W5 mm (in) 388 (15.3)
W6 mm (in) —
A1 degree 30
A2 degree 68
A3 degree 2
T1 mm (in) —
