DIGITAL NETWORK GAUGE RIGGING KIT CONTENTS

SQUARE STYLE GAUGE RIGGING KIT FOR EUROPE

TWIN KIT (TACH, TACH, SPEED/FUEL MGT) w/o Speed Sensor Kit

Kit P/N: 6YR-W0035-G0

TWIN KIT (TACH, TACH, SPEED, FUEL MGT) w/o Transom Wire Harness

Kit P/N: 6Y8-W0035-31

Part No. Part name Q’ty Remarks

61B-8258A-01 Main wire-harness 10-pin, 8 m (26 ft) 1

6K1-8258A-40 Main wire-harness 10-pin, 9.8 m (32 ft) 1

6Y8-81920-01 Multi-hub 3 With resistor cap, GRY

6Y8-82521-11 Pigtail bus wire, 0.6 m (2 ft) 4

6Y8-82521-31 Pigtail bus wire, 1.8 m (6 ft) 1

6Y8-82521-41 Pigtail bus wire, 2.7 m (9 ft) 1

6Y8-82553-01 Main bus wire, 0.3 m (1 ft) 1

6Y8-82553-31 Main bus wire, 7.6 m (25 ft) 1

6Y8-82582-01 2-pin cap, RED 2 For waterproof

6Y8-82582-11 4-pin cap, WHT 3 For waterproof

6Y8-8350F-01 SQR fuel mgt gauge 1

6Y8-8350S-01 SQR speedometer 1

6Y8-8350T-01 SQR tachometer 2

6Y8-83553-01 PWR supply wire, 2.4 m (8 ft) 1 With 10 amp fuse

6Y8-8356N-01 Fuel tank & GPS wire 1

704-48207-P1 Twin-binnacle RCL box, Premium 1

6Y8-82570-03 Twin-switch panel 1

90149-05M05 Screw, 25 mm (1 in) 4

95380-05600 Nut 4

92990-05600 PLN washer 4

92990-05100 SRG washer 4

6Y8-2819U-X2 Quick operation guide 1

6Y8-2819K-S1 Quick installation guide 1

6Y8-2819U-70 Operation manual 1 1

6Y8-2819U-80 Operation manual 2 1
