Yamaha F4B - Page 177

9-16
Clamp bracket
0
1
2
3
4
5
6
7
8
9
10
A
No. Part name Q’ty Remarks
18 Spring 1
19 Bushing 2
20 Plate 1
21 Bolt 2 M6  20 mm
22 Cover 1
23 Tilt lock lever 1
8
6
5
2
3
15
16
17
23
14
7
6
9
10
11
12
13
14
15
16
17
19
18
22
21
20
19
1
4
15 N·m (1.5 kgf·m, 11.1 ft·lb)
