Yamaha F4B - Dimensions and Clamp Bracket Details

3-2
Dimension
0
1
2
3
4
5
6
7
8
9
10
A
Dimension
Exterior F4BMH, F5AMH, F6CMH
(*1) Transom height
90°
69°
12°
425 (16.8) 325 (12.8)
222 (8.8) 181 (7.2)
153 (6.1)
134 (5.3)
383 (15.1)
63 (2.5)
259 (10.2)
341 (13.5)
409 (16.2)
130 (5.2)
L: 562 (22.2)
S: 435 (17.2)
L: 93 (3.7)
S: 71 (2.8)
L: 637 (25.1)
S: 555 (21.9)
L: 771 (30.4)
S: 644 (25.4)
503 (19.9)
191 (7.6)
395 (15.6)
430 (17.0)
39 (1.6)
104 (4.1)
0.6 (0.02)
S: 635 (25.0)
L: 753 (29.0)
(*1)
mm (in)
Outboard motor installation / Dimension
