6-9
FUEL
Fuel system
6. Connect the hoses d and f, and then
fasten them using the clamps c.
7. Connect the hose e, and then fasten it
using the clamp c.
8. Insert the protrusion a of the fuel tank j
into the grommet k.
9. Install the manual starter. See “Installing
the manual starter” (7-10).
Fuel cock screw i:
7 N·m (0.7 kgf·m, 5.2 ft·lb)
i
d
f
c
e
c
j
k
a
