Yamaha F50 - Page 66

Operation
60
TIP:
Release the fuel vapor contained in the fuel
tank.
6. While pressing and holding the pressure
relief tab under the fuel tank cap again,
turn the fuel tank cap counterclockwise
to remove it.
7. Fill the fuel tank with fuel. WARNING!
Do not overfill. Otherwise fuel can ex-
pand and overflow if the temperature
increases.
[EWM02610]
TIP:
 Wipe up any spilled gasoline immediately
with dry rags.
 Dispose of rags properly according to local
laws or regulations.
8. Turn the fuel tank cap clockwise to tight-
en until a click is heard.
9. Turn the air vent screw clockwise to
close it.
1. Pressure relief tab
2. Fuel tank cap
1. Pressure relief tab
2. Fuel tank cap
Fuel tank capacity:
25 L (6.60 US gal, 5.50 Imp.gal)
1
2
ZMU07446
1
2
ZMU07447
1. Fuel tank cap
ZMU07448
1
ZMU07449
