Yamaha F50 - Page 75

Operation
69
2. After stopping the engine, disconnect
the fuel hose from the fuel joint on the
outboard motor by turning it counter-
clockwise.
3. Install the fuel joint cap on the outboard
motor.
4. Disconnect the fuel hose from the fuel
joint on the fuel tank by turning it coun-
terclockwise.
5. Tighten the air vent screw by turning it
clockwise.
6. Remove the key if the boat will be left un-
attended.
TIP:
The engine can also be stopped by pulling
the cord and removing the clip from the en-
gine shut-off switch, then turning the main
switch to “ ” (off).
1. Fuel joint
2. Fuel hose
1. Fuel joint cap
2
1
ZMU07458
1
ZMU07459
1. Fuel joint
2. Fuel hose
1. Air vent screw
2
1
ZMU07443
1
ZMU07444
