Yamaha F6BMH - Removing;Installing the Steering Handle

STEERING HANDLE
STEERING HANDLE
REMOVING/INSTALLING THE STEERING HANDLE (SHORT HANDLE OF F6AMH,
F6BMH, F8CMH)
Step Job/Part Q'ty Remarks
1 Throttle cable 2
2 Stop switch lead 2
3 Grommet 1
4 Bolt (with washer) 1
5Plate 1
6 Bushing 1
7 Steering handle assembly 1
8 Plate washer 1
9 Wave washer 1
10 Bushing 1
11 Grommet 1
12 Nut 2
13 Bracket 1
Continued on next page.
7-1
