Operation
54
When using the portable fuel tank “A”, fill the
fuel tank according to the following proce-
dure.
1. Disconnect the fuel hose from the fuel
tank and tighten the air vent screw on the
fuel tank cap.
2. Remove the portable tank from the boat.
3. Fill the fuel tank with fuel, but do not
overfill. WARNING! Do not overfill. Oth-
erwise fuel can expand and overflow if
the temperature increases.
[EWM02611]
Wipe up any spilled gasoline immediately
with dry rags.
Dispose of rags properly according to local
laws or regulations.
4. Tighten the filler cap securely.
When using the portable fuel tank “B”, fill the
fuel tank according to the following proce-
dure.
1. Disconnect the fuel hose from the fuel
joint on the fuel tank.
Fuel tank capacity:
24 L (6.34 US gal, 5.28 Imp.gal)
