Operation
55
2. Turn the air vent screw clockwise to
close it.
3. Remove the fuel tank from the boat.
4. To loosen the air vent screw, turn it coun-
terclockwise until it stops.
5. While pressing and holding the pressure
relief tab under the fuel tank cap, slowly
turn the fuel tank cap counterclockwise
1/4 turn.
TIP:
Release the fuel vapor contained in the fuel
tank.
6. While pressing and holding the pressure
relief tab under the fuel tank cap again,
turn the fuel tank cap counterclockwise
to remove it.
7. Fill the fuel tank with fuel. WARNING! Do
not overfill. Otherwise fuel can expand
and overflow if the temperature in-
creases.
[EWM02611]
1. Fuel joint
2. Fuel hose
1. Air vent screw
1. Air vent screw
ZMU07443
21
1
ZMU07444
1
ZMU07445
1. Pressure relief tab
2. Fuel tank cap
1. Pressure relief tab
2. Fuel tank cap
1
2
ZMU07446
1
2
ZMU07447
