Specifications and requirements
22
EMU36352
Emergency equipment
Keep the following items onboard in case
there is trouble with the outboard motor.
● A tool kit with assorted screwdrivers, pliers,
wrenches (including metric sizes), and
electrical tape.
● Waterproof flashlight with extra batteries.
● An extra engine shut-off cord (lanyard) with
clip.
● Spare parts, such as an extra set of spark
plugs.
Consult your Yamaha dealer for details.
EMU25222
Emission control information
EMU25230
North American models
This engine conforms to U.S. Environmental
Protection Agency (EPA) regulations for ma-
rine SI engines. See the label affixed to your
engine for details.
EMU25243
Approval label of emission control certifi-
cate
This label is attached to the bottom cowling.
New Technology; (4-stroke/HPDI) EM
EMU39201
Manufactured date label
This label is attached to the clamp bracket.
1. Approval label location
1. Manufactured date label location
ZMU07060
EMISSION CONTROL INFORMATION EM
THIS ENGINE CONFORMS TO CALIFORNIA AND U.S. EPA EXHAUST
REGULATIONS FOR SI MARINE ENGINES. REFER TO THE OWNER'S
MANUAL FOR MAINTENANCE SPECIFICATIONS AND ADJUSTMENTS.
MEETS U.S. EPA EVAP STANDARDS USING CERTIFIED COMPONENTS.
FAMILY:
DISPLACEMENT: liters
SPARK PLUG:
FUEL: GASOLINE
FELs(HC+NOx / CO)
: / g/kW-hr
MAX POWER: kW
IDLE SPEED: ± rpm IN NEUTRAL
SPARK PLUG GAP (mm):
VALVE LASH (mm) IN: EX:
YAMAHA MOTOR CO.,LTD.
INFORMATION ANTIPOLLUTION EM
CE MOTEUR EST CONFORME AUX NORMES D’ÉMISSIONS EPA DES É.-U. ET DE LA
CALIFORNIE POUR MOTEURS MARINS À ÉTINCELLE. POUR LES SPÉCIFICATIONS ET LES
RÉGLAGES À EFFECTUER, CONSULTEZ LE MANUEL DU PROPRIÉTAIRE. INSTALLÉ AVEC
LES COMPOSANTS HOMOLOGUÉS, IL SATISFAIT AUX NORMES EVAP EPA DES É.-U.
YAMAHA MOTOR CO.,LTD.
FAMILLE :
CYLINDRÉE : litre
BOUGIE :
CARBURANT : ESSENCE
FELs(HC+NOx / CO)
: / g/kW-h PUISS. MAX. : kW
RALENTI : ± tr/mm AU POINT MORT
BOUGIE-ÉCARTEMENT (mm) :
JEU DE SOUPAPES (mm) ADM: ÉCH:
U6DR30E0.book Page 22 Friday, November 30, 2012 4:27 PM
