Yamaha F9.9 - Page 53

Operation
47
5. While pressing and holding the pressure
relief tab under the fuel tank cap, slowly
turn the fuel tank cap counterclockwise
1/4 turn.
TIP:
Release the fuel vapor contained in the fuel
tank.
6. While pressing and holding the pressure
relief tab under the fuel tank cap again,
turn the fuel tank cap counterclockwise to
remove it.
7. Fill the fuel tank with fuel. WARNING! Do
not overfill. Otherwise fuel can expand
and overflow if the temperature in-
creases.
[EWM02610]
TIP:
● Wipe up any spilled gasoline immediately
with dry rags.
● Dispose of rags properly according to local
laws or regulations.
8. Turn the fuel tank cap clockwise to tight-
en until a click is heard.
1. Air vent screw
1. Pressure relief tab
2. Fuel tank cap
1
ZMU07445
1
2
ZMU07446
1. Pressure relief tab
2. Fuel tank cap
Fuel tank capacity:
12 L (3.17 US gal, 2.64 Imp.gal)
1
2
ZMU07447
ZMU07461
U6DR30E0.book Page 47 Friday, November 30, 2012 4:27 PM
