Maintenance
85
2. Start the engine. Warm it up and keep the
idle speed for 5-10 minutes.
3. Stop the engine and leave it for 5-10 min-
utes.
4. Remove the top cowling.
5. Remove the oil filler cap. Pull out the dip-
stick and use the oil changer to extract
the oil completely.
When using an oil changer, skip steps 6 and
7.
6. Prepare a suitable container that holds a
larger amount than the engine oil capaci-
ty. Remove the drain screw and gasket
while holding the container under the
drain hole. Let the oil drain completely.
Wipe up any spilled oil immediately.
If the oil does not drain easily, change the tilt
angle or turn the outboard motor to port and
starboard to drain the oil.
7. Put a new gasket on the oil drain screw.
Apply a light coat of oil to the gasket and
install the drain screw.
If a torque wrench is not available when you
are installing the drain screw, finger tighten
the screw just until the gasket comes into con-
tact with the surface of the drain hole. Then
tighten 1/4 to 1/2 turn more. Tighten the drain
screw to the correct torque with a torque
wrench as soon as possible.
1. Oil filler cap
1. Oil changer
1. Drain screw
2. Gasket
Drain screw tightening torque:
24 Nm (2.45 kgf-m, 17.7 ft-lb)
2
1
ZMU07967
U6DR30E0.book Page 85 Friday, November 30, 2012 4:27 PM
