E
2-2
EMU00390
OPERATIONS OF CONTROLS
AND
OTHER FUNCTIONS
EMU14650
FUEL TANK
If your model included a portable fuel tank,
its parts and functions are as follows.
1 Fuel hose joint
2 Fuel meter (if equipped)
3 Fuel tank cap
4 Air vent screw (if equipped)
EMU00420
Fuel Hose Joint
This connector is provided for connecting or
disconnecting fuel hose.
EMU15310
Fuel Meter
This meter is on the fuel tank cap. It shows
the approximate amount of fuel remaining in
the tank.
EMU00450
Fuel Tank Cap
This cap is for filling fuel. To remove it, turn
it counterclockwise.
EMU00460
Air Vent Screw
This screw is on the fuel tank cap. To
loosen it, turn it counterclockwise.
6G8-9-1M-2 4/4/03 11:34 AM Page 3
