What to do if Yamaha Outboard Motor fuel management gauge shows incorrect fuel consumption?
If the fuel management gauge shows incorrect fuel consumption, the engine recognition might be wrong (especially for multi-applications). To fix this, default the engine number and turn the key switch on in order from the portside engine to re-memorize each engine number.
What to do if the Yamaha FL200AET gauge display does not wake up?
If the gauge display doesn't wake up, it could be due to a lack of electrical power or a damaged gauge. Try these steps: replace the fuse, securely connect the couplers, replace any damaged wires or hubs, or, if necessary, replace the gauge itself.
Why Yamaha FL200AET Outboard Motor illumination does not light?
If the illumination does not light, it could be due to a lack of electrical power or a damaged gauge. You should try replacing the fuse, connecting the couplers securely, replacing the damaged wire or hub, or replacing the gauge.
How to fix Yamaha FL200AET tachometer showing incorrect engine RPM?
If the tachometer shows an incorrect engine RPM, the engine recognition might be wrong (especially for multi-applications). To correct this, push the 'SET' button for 10 seconds to default the engine number, then memorize each engine number again.
What causes Yamaha Outboard Motor fuel management gauge to show incorrect remaining fuel?
If the fuel management gauge shows incorrect remaining fuel, the fuel capacity setting may be wrong (specifically for SQR Fuel mgt Gauge). Fill the tank with fuel, and set the correct fuel tank capacity.
What to do if Yamaha FL200AET gauge shows “----”?
If the gauge displays '----', it indicates that the digital signal is not being received. Check that the couplers are securely connected and replace any damaged bus wires or hubs.
Why Yamaha FL200AET Speedometer or Comb. Speedometer & Fuel mgt gauge shows incorrect fuel level?
If the speedometer or combination speedometer & fuel management gauge shows an incorrect fuel level, the fuel sensor selection is likely wrong. Set up the fuel sensor to the correct resistance.
How to fix Yamaha FL200AET trim gauge showing incorrect position?
If the trim gauge shows an incorrect position, the initial position setting might be wrong, or the trim sender could be damaged. Put the motor in the fully trimmed-in position and reset the initial (zero) trim angle. If that doesn't work, replace the trim sender.
Why Yamaha FL200AET Outboard Motor gauge operates unstably?
If the gauge operates unstably, it could be because a resistor is not connected to the ending hubs. Connect the gray 6-pin cap to the ending multi-hubs.
What causes Yamaha FL200AET Outboard Motor gauge response to be poor or down?
If the gauge response is poor or down, a market obtainable unit connected to the system may have failed, or the signal volume has exceeded 50% of the capacity. Try replacing the unit or removing the heavy signal output unit.
General| Prop Shaft Horsepower | 200 hp |
|---|---|
| Full Throttle RPM Range | 5000 - 6000 rpm |
| Compression Ratio | 10.3:1 |
| Exhaust | Through Propeller |
| Lubrication System | Wet Sump |
| Starting System | Electric |
| Bore x Stroke | 96.0 x 96.2 mm |
| Fuel Induction System | EFI |
| Ignition / Advance System | TCI |
| Gear Ratio | 1.86:1 |
| Weight | 227 kg |
| Cooling System | Water Cooled |
| Displacement | 2785cc (169.9 ci) |
Failure to follow WARNING instructions could result in severe injury or death.
Step-by-step guide for safely uncrating the outboard motor from a steel frame.
Provides guidance on proper outboard motor mounting for optimal performance and reliability.
Procedure and requirements for installing the remote oil tank for specific engines.
Comprehensive dimension data for various 2-stroke outboard motor models.
Comprehensive dimension data for various 4-stroke outboard motor models.
Dimensional specifications for clamp brackets across different outboard motor models.
Guidance on selecting the appropriate propeller based on engine speed and load.
List of propeller applications for various Yamaha outboard motor models in 2009.
Overview of Yamaha remote control systems and their applications.
Information on tiller handle kits for various Yamaha engines, including US and Japan models.
Specifications and applications for analog tachometer gauges.
Specifications and applications for digital tachometer gauges.
Details on speedometer functions, applications, and dimensions.
Information on fuel management gauge functions, applications, and setup.
Wiring diagram for digital meters on single-engine setups.
Wiring diagram for digital meters with side-mount remote control.
Wiring diagram for digital meters with binnacle remote control.
Wiring diagram for digital meters on twin-engine setups with binnacle RC.
Wiring diagram for analog meters on 2-stroke engines.
Wiring diagram for analog meters on 2- and 4-stroke engines.
Wiring diagrams for single, twin, and triple engine digital network gauge setups.
Procedure for initial setup of digital network gauges for multi-engine installations.
Common troubleshooting steps for digital network gauge system issues.
Guidance on selecting the correct battery capacity and type for Yamaha outboards.
Wiring instructions for single and multi-engine battery setups with isolators.
Requirements for extending battery cables based on capacity, size, and temperature.
Checklist for pre-delivery inspection to ensure customer satisfaction.
Components included in the digital tachometer and speedometer rigging kit.
