Yamaha FT8DMH Rigging Guide

4-4
6X4 MULTI-FUNCTION TILLER HANDLE
F75, F90
KIT P/N:6X4-42102-10
F50, T50, F60, T60
KIT P/N:6X4-42102-21
Part name Part No. Q’ty Remarks
Fuel pipe clamp 2 63D-24367-00 1
Cable clamp 63D-48538-00 2
Throttle cable 67G-26301-10 1 895 mm (35 in.)
Shift cable 67G-48321-20 1 965 mm (40 in.)
Grommet 2 68V-42725-10 1
Corrugated tube 6G5-83557-00 1 85 mm (3.3 in.)
Corrugated tube 6K3-83557-00 1 65 mm (2.6 in.)
Stay 6X4-24364-00 1
Ext. bracket
6X4-42121-00-4D 1 45 mm (Short)
Troll RPM switch assy 6X4-81860-00 1
10-pin main harness 6X4-82586-20 1 1250 mm (49 in.)
Stud bolt 90116-10031 2 M10-70 mm
Lock nut 90185-10051 2 M10
Corrugated tube 90447-22007 1 230 mm (9.1 in.)
Clamp 90464-09M42 1
Clamp 90465-13M24 5
Clamp 90465-13M30 1
Clip 90468-10005 2
Bolt 97595-06516 2
Protector 6X4-42735-00 1
Steering friction assy 67G-42508-10 1
Part name Part No. Q’ty Remarks
Cable clamp 2 63D-48538-00 2
Shift cable 67C-48321-11 1 707 mm (28 in.)
Throttle cable 69W-26301-00 1 610 mm (24 in.)
Grommet 2 6C5-42725-30 1
Troll RPM switch assy 6X4-81860-00 1
10-pin main harness 6X4-82586-10 1 950 mm (37 in.)
Lock nut 90185-10051 2
Clamp 90464-09M42 1
Clamp 90465-13M36 1
Clip 90468-10005 2
Steering friction assy 6C5-42508-00 1
