4-5
6X4 MULTI-FUNCTION TILLER HANDLE
F40B
KIT P/N:6X4-42102-31
90
KIT P/N:6X4-42102-41
Part name Part No. Q’ty Remarks
Grommet 2 62Y-42725-30 1
Cable clamp 63D-48538-00 2
Shift cable 67C-48321-11 1 707 mm (28 in.)
Throttle cable 69W-26301-00 1 610 mm (24 in.)
10-pin main harness 6X4-82586-00 1 700 mm (26 in.)
Lock nut 90185-10051 2 M10
Clamp 90464-09M42 1
Clamp 90465-13M36 1
Clip 90468-10005 2
Steering friction assy 67C-42508-03 1
Part name Part No. Q’ty Remarks
Cable clamp 63D-48538-00 2
Throttle cable 6H1-26301-01 1 610 mm (24 in.)
Shift cable 6H1-48321-11 1 726 mm (29 in.)
Ext. bracket
6X4-42121-00-4D
1 45 mm (Short)
Shift handle
6X4-44159-10-4D
1
Short type (exclusive), To replace original lever
Shift lever 6X4-44173-00 1
Screw 97780-60920 2
Bush 90386-26MA3 1
10-pin main harness 6X4-82586-30 1 700 mm (26 in.)
Stud bolt 90116-10031 2 M10-70 mm
Clamp 90464-09M42 1
Clamp 90464-15M11 1
Clamp 90465-13M36 2
Clip 90468-10005 2
Bolt 97595-08540 1
Steering friction assy 692-42508-01 1 Shaft type
