10-1
10
EBU25961
SPECIFICATIONS
Dimensions:
Overall length:
1700 mm (66.9 in)
Overall width:
990 mm (39.0 in)
Overall height:
980 mm (38.6 in)
Seat height:
685 mm (27.0 in)
Wheelbase:
1080 mm (42.5 in)
Ground clearance:
145 mm (5.7 in)
Minimum turning radius:
2900 mm (114 in)
Weight:
With oil and fuel:
152.0 kg (335 lb)
Noise and vibration level:
Noise level (77/311/EEC):
78.0 dB(A)@3500 r/min
Vibration on seat (EN1032, ISO5008):
Will not exceed 0.5 m/s²
Vibration on handlebar (EN1032, ISO5008):
Will not exceed 2.5 m/s²
Engine:
Engine type:
Air cooled 4-stroke, SOHC
Cylinder arrangement:
Single cylinder
Displacement:
124 cm³
Bore × stroke:
49.0 × 66.0 mm (1.93 × 2.60 in)
Compression ratio:
9.00 : 1
Starting system:
Electric starter
Lubrication system:
Wet sump
Engine oil:
Recommended brand:
YAMALUBE
U1PY61E0.book Page 1 Wednesday, March 14, 2012 5:22 PM
