DESCRIPTION
2-2
2
1. Storage compartment (page 3-11)
2. Shock absorber assembly (page 3-12)
3. Final transmission oil filler cap (page 6-7)
4. Adjusting nut (page 6-13)
5. Final transmission oil drain bolt (page 6-7)
6. Kickstarter (page 3-10)
7. Air filter element (page 6-9)
8. Coolant level check window (page 6-8)
9. Front brake pads (page 6-14)
