Yamaha JOGR JOGRR CS50 - Controls and Instruments

DESCRIPTION
2-5
2
1. Rear brake lever (page 3-7)
2. Left handlebar switches (page 3-6)
3. Speedometer (page 3-3)
4. Multi-function display (page 3-4)
5. Main switch/steering lock (page 3-1)
6. Right handlebar switch (page 3-6)
7. Throttle grip (page 6-10)
8. Front brake lever (page 3-6)
EAU32240
Controls and instruments
CS50/CS50M/CS50Z
1
2
34
5
67
8
