EAU26490
Model label
1. Model label
The model label is affixed to the bot-
tom of the seat. (See page 3-11).
Record the information on this label in
the space provided. This information
will be needed when ordering spar
e
parts from a Y
amaha dealer
.
1
CONSUMER INFORMA
TION
9-2
9
72
74
