5. Place the bulb holder in its origi-
nal position, and then secure it
with the retaining wire as shown.
6. Connect the headlight leads and
install the cowling.
7. Have a Yamaha dealer adjust the
headlight beam if necessary.
Left turn signal light bulb
1. Remove cowling A. (See page
6-5).
2. Remove the socket (together
with the bulb) by turning it coun-
terclockwise.
1. Socket
3. Remove the burnt-out bulb from
the socket by pulling it out.
1. Turn signal light bulb
4. Insert a new bulb into the socket.
5. Install the socket by turning it
clockwise.
6. Install the cowling.
Right turn signal light bulb
1. Remove cowling A. (See page
6-5).
2. Remove the socket (together
with the bulb) by turning it clock-
wise.
1. Socket
3. Remove the burnt-out bulb from
the socket by pulling it out.
4. Insert a new bulb into the socket.
5. Install the socket by turning
counterclockwise.
6. Install the cowling.
