8-43
8
must be adjusted by a Yamaha dealer at the inter-
vals specified in the periodic maintenance and lu-
brication chart.
EBU24072
Adjusting the drive select lever safety
system cable
The drive select lever safety system cable stretch-
es with use, which can result in improper function.
Therefore, the safety system cable should be
checked and adjusted by a Yamaha dealer at the
intervals specified in the periodic maintenance
and lubrication chart.
EBU29602
Brakes
Replacement of brake components requires pro-
fessional knowledge. Brake service should be
performed by a Yamaha dealer.
EWB02572
Operating with improperly serviced or adjust-
ed brakes could lead to a loss in braking ability
and an accident.
EBU28414
Checking the front brake pads and rear
brake friction plates
The front brake pads and the rear brake friction
plates must be checked for wear at the intervals
specified in the periodic maintenance and lubrica-
tion chart.
This ATV is equipped with a wet, multiple-disc
type rear brake, which is located inside of the final
gear case.
EBUM0191
Front brake pads
Each brake pad is provided with a wear indicator
groove, which allows you to check the brake pad
wear without having to disassemble the brake. To
check the brake pad wear, check the wear indica-
tor groove. If a brake pad has worn to the point
that the wear indicator groove has almost disap-
peared, have a Yamaha dealer replace the brake
pads as a set.
UB1660E0.book Page 43 Thursday, February 26, 2015 4:01 PM
