27
DX200
●
LED CIRCUIT BOARD
Component side
to PN CN1
Note: See parts list for details of circuit board component parts.
SONG PATTERN STORE
PITCH GATE TIME VELOCITY
INST SEL BPM BEAT
LED: 2NA-V488650
