Yamaha MODX8 User Manual

MODX Reference Manual
7
Basic Structure
Functional blocks
Tone Generator block
A/D Input block
Sequencer block
Arpeggio block
Motion Sequencer block
Effect block
Envelope Follower block
Controller block
Internal Memory
Reference
Display (touch panel) config.
Performance Play (Home)
Motion Control
Mixing
Scene
Play/Rec
Normal Part (AWM) Edit
Drum Part Edit
Normal Part (FM-X) Edit
Common/Audio Edit
Category Search
Utility
Live Set
iPhone/iPad connection
For details on the Motion Control, refer to the website below:
http://www.yamaha.com/modx/
Motion Control System Structure
• Continuous control of
Motion changes
• Switch between Motions
• Trigger, Hold
Control the Motion
Sequencer in real time
AUDIO BEAT
• Part 1–16
• A/D Input Part
• Audio Beat Sync
• External MIDI
• Internal Tempo
Envelope Follower Motion Sequencer
Super Knob
Rhythmic change
Automation
Multi-dimensional
sonic change
Tone generator
Effect

Yamaha MODX8 Specifications

General

Type	Synthesizer
Aftertouch	No
Arpeggiator	Yes
Headphones	1 x 1/4"
Storage	USB Flash Drive
Keyboard	88-key
Sound Engine	AWM2, FM-X
Polyphony	AWM2: 128, FM-X: 64
Preset Voices	Over 2000
User Memory	1 GB
Effects	Reverb, Chorus, Part EQ
Display	7-inch TFT Color LCD
Weight	13.8 kg (30.4 lbs)
Presets	2, 370 Voices + 35 Drum Kits
Sequencer	16-track
Audio Inputs	2 x 1/4"
Audio Outputs	2 x 1/4"
USB	1 x USB to host, 1 x USB to device
MIDI I/O	In/Out
Pedal Inputs	2 x 1/4" (sustain, assignable)
