General specifications
Type........................................... Amplified 2Way Bass Reflex Powered Speaker (Bi-Amp.)
Crossover Frequency.................. 2.0 kHz, 30 dB/oct
Frequency Range ....................... 40 Hz to 40 kHz (–10 dB)
Sensitivity .................................. –10 dB at –6 dB position (for 100 dB/SPL, 1 m on Axis)
Maximum Output Level ............. 110 dB (1 m on Axis)
Dimensiones (W × H × D).......... 265 × 420 × 329 mm
Weight....................................... 20 kg
Speaker unit
Speaker Unit .............................. LF: 20 cm Cone (4Ω, magnetic shielded)
HF: 2.5 cm Titan Dome (8Ω, magnetic shielded)
Enclosure ................................... Type: Bass Reflex
Amp.unit
Maximum Output Power............ LF: 120 W at 400 Hz, THD= 0.02%, RL= 4Ω
HF: 60 W at 10 kHz, THD= 0.02%, RL= 8 Ω
Input Sensitivity/Impedance ....... –6 dB to +4 dB/10 kΩ
Hum & Noise.............................≤–67 dBu (Volume= Min) DIN Audio filter
Signal to Noise Ratio.................. ≥98 dB (IEC-A Weighting)
Controls ..................................... TRIM Switch
LOW: 3 positions (0 dB, –1.5 dB, –3 dB at 50 Hz)
HIGH: 3 positions (+1.5 dB, 0 dB, –1.5 dB at 10 kHz)
LOW CUT Switch: ON/OFF
SENSITIVITY Control
POWER Switch: ON/OFF
Connectors ............................... Input XLR-3-31
Power Indicator/Clip Indicator ... Green/Red LED
Power Requirement.................... USA and Canada: AC 120 V, 60 Hz
Europe: AC 230 V, 50 Hz
Others: AC 240 V, 50 Hz
Power Consumption................... 150 W
Option ....................................... Wall mounting bracket BWS251-300
3
MSP10
SPECIFICATIONS
