PERIODIC MAINTENANCE AND MINOR REPAIR
6-30
6
EAU24181
Tail/brake light
This model is equipped with an LED-
type tail/brake light.
If the tail/brake light does not come on,
have a Yamaha dealer check it.
EAU24202
Replacing a turn signal light
bulb
1. Remove the turn signal light lens
by removing the screw.
2. Remove the defective bulb by
pushing it in and turning it counter-
clockwise.
3. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
4. Install the lens by installing the
screw.
CAUTION:
ECA11190
Do not overtighten the screw, other-
wise the lens may break.
EAU36810
Replacing the license plate
light bulb
1. Remove the license plate light cov-
er by removing the screws.
2. Remove the license plate light lens
by removing the screws.
1. Screw 1. Screw
2. License plate light cover
U5YUE3E0.book Page 30 Thursday, September 20, 2007 3:03 PM
