TE:
Skip steps 2 and 7 if the auxiliary light
bulb A is being replaced.
2. To replace auxiliary light bulb B or
C, remove the corresponding
headlight unit side cover bracket
and the headlight unit side cover
by removing the screws.
3. Remove the socket (together with
the bulb) by turning it counter-
clockwise.
4. Remove the defective bulb by pull-
ing it out.
5. Insert a new bulb into the socket.
6. Install the socket (together with the
bulb) by turning it clockwise.
7. Install the headlight unit side cover
and the headlight unit side cover
bracket by installing the screws.
8. Install the headlight unit by install-
ing the bolts.
1. Bolt 1. Screw
2. Headlight unit side cover bracket
3. Headlight unit side cover
1. Auxiliary light bulb socket
1. Auxiliary light bulb
U5YUE3E0.book Page 32 Thursday, September 20, 2007 3:03 PM
