Instrument and control functions
4-16
4
ECA10702
Use only unleaded gasoline. The use
of leaded gasoline will cause unre-
pairable damage to the catalytic
converter.
EAU57991
Seat
To remove the seat
1. Open the seat lock cover, insert
the key into the seat lock, and then
turn the key counterclockwise.
2. While holding the key in that posi-
tion, lift the rear of the seat up, and
then pull the seat off.
To install the seat
1. Insert the projections into the seat
holders as shown.
2. Push the rear of the seat down to
lock it in place.
3. Remove the key.
Make sure that the seat is properly se-
cured before riding.
1. Seat lock cover
2. Seat lock
3. Turn.
UB7DE0E0.book Page 16 Tuesday, September 18, 2018 3:25 PM
