Yamaha MT-25 - Vehicle Lights; Replacing the License Plate Light Bulb

7-32
Periodic maintenance and adjustment
7
This model is equipped with LED lights
for headlights, auxiliary lights and
brake/tail light. If a light does not come
on, check the fuse and then have a
Yamaha dealer check the vehicle.
NOTICE
ECA16581
Do not afx any type of tinted lm or
stickers to the headlight lens.
1. Auxiliary light
2. Headlight (low beam)
3. Headlight (high beam)
Vehicle lights
EAU62670
Replacing the license plate
light bulb
1. Remove the mudguard by remov-
ing the quick fasteners.
2. Remove the rear fender lower
panel by removing the bolts and
screws.
3. Remove the license plate light
bulb socket (together with the
bulb) by pulling it out.
4. Remove the burnt-out bulb by
pulling it out.
1. Mudguard
2. Quick fastener
1
2
1. Bolt
2. Screw
3. Rear fender lower panel
1. License plate light bulb
2. License plate light bulb socket
3
2
1
2
2
1
2
1
