MW8CX/MW10C Owner’s Manual
91
■ Analog Input Specifications
Where 0 dBu = 0.775 Vrms and 0 dBV= 1 Vrms
** Sensitivity : The lowest level that will produce an output of +4 dB (1.23 V), or the nominal output level when the unit is set to
the maximum level. (All level controls are at their maximum position.)
■ Analog Output Specifications
Where 0 dBu = 0.775 Vrms and 0 dBV= 1 Vrms
* The MW8CX feature is described first, followed by the MW10C feature in brackets: MW8CX (MW10C)
■ Digital Input/Output Specifications
Input Connectors Gain
Input
Impedance
Appropriate
Impedance
Sensitivity **
Nominal
Level
Max. before
Clipping
Connector
Specifications
CH INPUT MIC
(CHs 1, 2)
-60 dB
3 kΩ
50–600 Ω
Mics
-72 dBu
(0.195 mV)
-60 dBu
(0.775 mV)
-40 dBu
(7.75 mV)
XLR-3-31 type (balanced [1 = GND, 2
= HOT, 3 = COLD])
-16 dB
-28 dBu
(30.8 mV)
-16 dBu
(123 mV)
+4 dBu
(1.23V)
CH INPUT LINE
(CHs 1, 2)
-34 dB
10 kΩ
600 Ω
Lines
-46 dBu
(3.88 mV)
-34 dBu
(15.5 mV)
-14 dBu
(155 mV)
TRS phone jack (balanced [Tip =
HOT, Ring = COLD, Sleeve = GND])
+10 dB
- 2 dBu
(0.615 V)
+10 dBu
(2.45 V)
+30 dBu
(24.5 V)
ST CH MIC INPUT
(CHs 3/4, 5/6)
-60 dB
3 kΩ
50–600 Ω
Mics
-72 dBu
(0.195 mV)
-60 dBu
(0.775 mV)
-40 dBu
(7.75 mV)
XLR-3-31 type (balanced [1 = GND, 2
= HOT, 3 = COLD])
-16 dB
-28 dBu
(30.8 mV)
-16 dBu
(123 mV)
-6 dBu
(389 mV)
ST CH LINE
INPUT
(CHs 3/4, 5/6)
-34 dB
10 kΩ
600 Ω
Lines
-46 dBu
(3.88 mV)
-34 dBu
(15.5 mV)
-14 dBu
(155 mV)
Phone jack (unbalanced)
+10 dB
- 2 dBu
(0.615 V)
+10 dBu
(2.45 V)
+30 dBu
(24.5V)
ST CH INPUT
(CH 7/8 (CHs 7/8,
9/10)*)
— 10 kΩ
600 Ω
Lines
-22 dBu
(61.5 mV)
-10 dBu
(245 mV)
+10 dBu
(2.45 V)
Phone jack (unbalanced)
RCA pin jack
CH INSERT IN
(CHs 1, 2)
— 10 kΩ
600 Ω
Lines
-12 dBu
(195 mV)
0 dBu
(0.775 V)
+20 dBu
(7.75 V)
TRS phone jack (unbalanced [Tip =
Out, Ring = In, Sleeve = GND])
RETURN (L, R) — 10 kΩ
600 Ω
Lines
- 8 dBu
(308 mV)
+4 dBu
(1.23 V)
+24 dBu
(12.3 V)
Phone jack (unbalanced)
2TR IN (L, R) — 10 kΩ
600 Ω
Lines
-22 dBV
(79.4 mV)
-10 dBV
(0.316 V)
+10 dBV
(3.16 V)
RCA pin jack
Output Connectors
Output
Impedance
Appropriate
Impedance
Nominal Level
Max. before
clipping
Connector Specifications
STEREO OUT (L, R) 150 Ω 10 kΩ Lines +4 dBu (1.23 V) +20 dBu (7.75 V)
TRS phone jack (impedance balanced
[Tip = HOT, Ring = COLD, Sleeve = GND])
EFFECT SEND
(AUX SEND*)
150 Ω 10 kΩ Lines +4 dBu (1.23 V) +20 dBu (7.75 V)
TRS phone jack (impedance balanced
[Tip = HOT, Ring = COLD, Sleeve = GND])
CH INSERT OUT
(CHs 1, 2)
75 Ω 10 kΩ Lines 0 dBu (0.775 V) +20 dBu (7.75 V)
TRS phone jack (unbalanced [Tip = OUT,
Ring = IN, Sleeve = GND])
REC OUT (L, R) 600 Ω 10 kΩ Lines -10 dBV (0.316 V) +10 dBV (3.16 V) RCA Pin jack
MONITOR OUT (L, R) 150 Ω 10 kΩ Lines +4 dBu (1.23 V) +20 dBu (7.75 V)
TRS phone jack (impedance balanced
[Tip = HOT, Ring = COLD, Sleeve = GND])
PHONES OUT 100 Ω 40 Ω Phones 3 mW 75 mW TRS phone jack
Connector Format Data Length Connector Specification
USB USB Audio 1.1 16 bit USB B type

Yamaha MW10c Specifications
