DRX-730/NX-E700
DRX-730/NX-E700
■ SPECIFICATIONS
■ Amplifier Section
Maximum Power (JEITA, 6 ohms, 1 kHz, 10 % THD)
SP OUT ........................................................... 30 W + 30 W
Minimum RMS Output Power (6 ohms, 1 kHz, 0.9 % THD)
SP OUT ........................................................... 20 W + 20 W
Input Sensitivity/Input Impedance (1 kHz, 20 W)
AUX, PORTABLE ..................................... 400 mV/47 k-ohms
Maximum Input Signal Level (1 kHz, 0.5 % THD)
AUX, PORTABLE .............................................2.2 V or more
Output Level/Output Impedance (400 mV)
REC OUT (1 kHz) .................................. 400 mV/1.2 k-ohms
WOOFER PRE OUT (50 Hz) ........................ 2.0 V/1 k-ohms
HEADPHONE (1 kHz, 32 ohms) ............. 660 mV/100 ohms
Frequency Response (AUX, PORTABLE, 10 to 22 kHz)
SP OUT ..................................................................... 0/-3 dB
Signal to Noise Ratio (AUX, PORTABLE, IHF-A)
SP OUT (Input shorted 400 mV) ..................95 dB or more
Total Harmonic Distortion
(AUX, PORTABLE, 20 kHz-LPF, 1 kHz, 1 W)
SP OUT ..........................................................0.05 % or less
Tone Control Characteristics
BASS
SP OUT (100 Hz) ................................................... ±10 dB
TREBLE
SP OUT (10 kHz) ................................................... ±10 dB
■ Tuner Section
Tuning Range
FM
U, C models ......................................... 87.5 to 107.9 MHz
T, K, A, G, F models ....................... 87.50 to 108.00 MHz
L, V models .............87.5 to 108.0 / 87.50 to 108.00 MHz
AM
U, C models ........................................... 530 to 1,710 kHz
T, K, A, G, F models ............................. 531 to 1,611 kHz
L, V models ....................530 to 1,710 / 531 to 1,611 kHz
■ DVD Section
Output Level (DVD/VIDEO, CD/CD-DA)
REC OUT (1 kHz, 0 dB) ........................................ 2 ±0.3 V
Signal to Noise Ratio (DVD/VIDEO, CD/CD-DA)
REC OUT (Weighted) ..................................100 dB or more
Dynamic Range
REC OUT
DVD, 48 kHz, 24 bit ...................................95 dB or more
CD-DA/VIDEO, CD ......................................95 dB or more
Harmonic Distortion + Noise (DVD/VIDEO, CD/CD-DA)
REC OUT .....................................................0.005 % or less
Frequency Response
PRE OUT
CD-DA/VIDEO, CD ...................................10 Hz to 20 kHz
DVD, 48 kHz, sampling ...........................10 Hz to 22 kHz
DVD, 96 kHz, sampling ...........................10 Hz to 44 kHz
Video Output
Composite .................................................1 Vp-p (75 ohms)
Y Output/Component Video Output
..................................................................1 Vp-p (75 ohms)
Pb Output/Component Video Output
...............................................................0.7 Vp-p (75 ohms)
Pr Output/Component Video Output
...............................................................0.7 Vp-p (75 ohms)
RGB AV MONITOR OUT (SCART) Output [G, F models]
...............................................................0.7 Vp-p (75 ohms)
■ Input/Output Section
Input Terminal
Analog audio ............................... AUX L/R (pin jack – rear)
PORTABLE (mini jack – front)
Other ...........................................USB (USB 1.1, full speed)
DOCK
Output Terminal
Analog audio ................................................ SPEAKERS L/R
PHONES
AUX L/R (REC)
SUBWOOFER
Digital audio ...........................................................OPTICAL
Video .......................................................VIDEO (composite)
COMPONENT (Y, P
B
, P
R
)
HDMI
AV MONITOR OUT (SCART) (G, F models)
■ General
Power Supply
U, C models ..................................................... AC 120 V, 60 Hz
T model ............................................................ AC 220 V, 50 Hz
K model ............................................................ AC 220 V, 60 Hz
A model ............................................................ AC 240 V, 50 Hz
G, F models ..................................................... AC 230 V, 50 Hz
L model ................................................ AC 220-240 V, 50/60 Hz
V model ............................................................ AC 110 V, 60 Hz
Power Consumption
......................................................................................30 W
Standby Power Consumption (reference data)
.......................................................................Less than 1 W
Dimensions (W x H x D)
...........215 x 113 x 300 mm (8-7/16" x 4-7/16" x 11-13/16")
Weight
...............................................................2.9 kg (6 lbs. 6 oz.)
Finish
Gold color .......................................................... T, A models
Black color ......................................U, A, G, F, L, V models
Silver color ................................. C, K, A, G, F, L, V models
White color ..........................................C, K, A, G, F models
Accessories
Remote control ................................................................ x 1
Battery (R6, AA, UM-3) ................................................... x 2
Indoor FM antenna (1.4 m) ............................................. x 1
AM loop antenna (1.2 m) ................................................ x 1
Video pin cable (1.5 m) .................................................. x 1
* Specifications are subject to change without notice due to product
improvements.
