DRX-730/NX-E700
49
IC505
IC502
SUB (1) P.C.B. (Side B)
18
169
KAR
T, K, A, G, L, F models
T, K, A, G, L, F models
• Semiconductor Location
Ref no. Location
D503 F4
D508 E3
D509 E3
D512 C3
D517 H3
D518 E5
D519 E5
D521 B3
IC502 F5
IC505 C5
