60
DRX-730/NX-E700
DRX-730/NX-E700
Ref No. Part No. Description Markets Ref No. Part No. Description Markets
* IC2 X9799A00 IC R2A15908SP
IC3 X7889A00 IC PCM1753DBQR
IC4 X8235A00 IC LC72725KM GF
IC5 X7974A00 IC KIA7809API-U/P
IC6 X8705A00 IC KIA78M05F
* IC7 X9908A00 IC 74AHCT541PW TSSOP
IC8 X2331A00 IC NJM4580E OP AMP
IC9 X4153A00 IC KIA7812API
* IC10 X9825A00 IC BD9778HFP
* IC11 YA013A00 IC.CPU R5F3640DNFA CPU
(unwritten)
IC12 X7651A00 IC BD9302FP-E2
* IC13 X9563A00 IC MIC2005-0.5YM6 SOT23-6
* IC14 X9823A00 IC TDA8922BTH
* IC15 X9888A00 IC BA50DD0WHFP
IC16 XR680A00 IC TC7SH08FU(TE85L,JF
IC17 XS775A00 IC TC7SH04FU
IC20 XV892B00 IC TC74VHC74FT(EL,K)
IC21 X2331A00 IC NJM4580E OP AMP
IC26 X2331A00 IC NJM4580E OP AMP
IC27 X7444A00 IC KIA78L05F-RTF/P
* IC28 YA171A00 IC TS3V340PWR PW GF
IC29 X8294A00 IC M24C02-WDW6TP
PJ1 WG089100 JACK.PIN JACK 4P R/BE/G/Y
PJ2 WF342300 JACK.PIN MSP-241V2
PJ3 V7046700 JACK.PIN 4P MSP-244V1-01NI
PN1-4 V9637500 PIN L=70 #18
Q1-2 VV556400 TR 2SC2412K Q,R,S
Q3-4 VZ725900 TR 2SD1938F S,T
Q6 VV556400 TR 2SC2412K Q,R,S
Q8 VV655700 TR.DGT DTC144EKA GF
Q9 VZ725900 TR 2SD1938F S,T
Q10 VV556400 TR 2SC2412K Q,R,S GF
Q12 VZ725900 TR 2SD1938F S,T
Q13 VV556400 TR 2SC2412K Q,R,S GF
Q15 VV655700 TR.DGT DTC144EKA GF
Q16 WC529500 TR KTA1504S Y GR RTK GF
Q18 VV655700 TR.DGT DTC144EKA GF
Q19 VV556400 TR 2SC2412K Q,R,S GF
Q20-22 VZ725900 TR 2SD1938F S,T
Q23-24 WC529500 TR KTA1504S Y GR RTK
Q25-27 VZ725900 TR 2SD1938F S,T
Q28-29 WC529500 TR KTA1504S Y GR RTK
Q31-32 WC529500 TR KTA1504S Y GR RTK
Q36 VV556400 TR 2SC2412K Q,R,S
Q37-40 VV655700 TR.DGT DTC144EKA
Q41-42 VV655300 TR.DGT DTA144EKA
Q43 VV655700 TR.DGT DTC144EKA
Q44 VV556400 TR 2SC2412K Q,R,S
Q45 VV655700 TR.DGT DTC144EKA
Q46 VV556400 TR 2SC2412K Q,R,S
Q47 VV655700 TR.DGT DTC144EKA
Q48 WC529500 TR KTA1504S Y GR RTK
Q49 VP872600 TR 2SA1708 S,T
Q50 VV655700 TR.DGT DTC144EKA GF
Q51-54 VZ725900 TR 2SD1938F S,T
R16 HV754100 R.CAR.FP 10 Ω 1/4W
R73-75 VY893200 R.MTL.OXD 12 Ω 1W
R115 WB785000 R.MTL.OXD 18 Ω 1W J
R176 HV754100 R.CAR.FP 10 Ω 1/4W
R180 HV754100 R.CAR.FP 10 Ω 1/4W
R184 HV754100 R.CAR.FP 10 Ω 1/4W
R185 V9199400 R.MTL.OXD 1.2K Ω 1W
R187 HV753220 R.CAR.FP 2.2 Ω 1/4W
R190 HV754100 R.CAR.FP 10 Ω 1/4W
R193 HV753680 R.CAR.FP 6.8 Ω 1/4W
R199 VP940200 R.MTL.OXD 47 Ω 1W
R205 WB785000 R.MTL.OXD 18 Ω 1W J
R206 VP940200 R.MTL.OXD 47 Ω 1W
R211 WB785000 R.MTL.OXD 18 Ω 1W J
R320 VU224000 R.MTL.FLM 0.22 Ω 1W
R325 VU224000 R.MTL.FLM 0.22 Ω 1W
R332 VU224000 R.MTL.FLM 0.22 Ω 1W
R372-373 VP940000 R.MTL.OXD 22 Ω 1W
TE1 WD039300 TERM.SP 4P LQR2411-0001FM UCTAV
TE1 WD039400 TERM.SP 4P LQR2411-0003FM KGFL
U1 WH536900 CN.PHOTO.T 1P GP1FAV51TK0F
XL1 WJ588000 RSNR.CRYS 4.332MHz GF
XL2 VQ328900 RSNR.CRYS 32.768KHz
XL3 WB440500 RSNR.CE CSTCE16M0V53-R0
WE807300 SHEET.RD 19x24
WE774400 SCR.BND.HD 3x8 MFZN2B3
* WQ229000 P.C.B. SUB UC
* WQ229100 P.C.B. SUB TK
* WQ229200 P.C.B. SUB A
* WQ229300 P.C.B. SUB GFL
* WQ229400 P.C.B. SUB V
CB501 VG879900 CN.BS.PIN 2P
CB502-503 WN103000 CLIP.FUSE TP00351-31
CB801 WB832600 CN 6P TE
CB806 V5766700 CN 30P TE
* CB807 WQ092000 CN.USB 4P TE
C501 V5877700 C.MYLAR 0.22uF 250V
C502 WH036100 C.CE.SAFTY 2200pF 250V UCV
C502-503 WH035900 C.CE.SAFTY 1000pF 250V TKAGFL
C503 WH035900 C.CE.SAFTY 1000pF 250V TKAGFL
C504 WN826300 C.CE.SAFTY 0.01uF 250V
C507 V5877700 C.MYLAR 0.22uF 250V
C508 US063100 C.CE.CHP 1000pF 50V B
C510 WD969200 C.CE.CHP 0.1uF 50V K
* C511 WP573900 C.EL 560uF 200V UCV
* C511 WP574000 C.EL 150uF 400V TKAGFL
* C512 WP340600 C.EL 47uF 35V
C513 WJ322400 C.CE.M.CHP 0.01uF 250V UCV
C513 WJ322300 C.CE.M.CHP 1000pF 630V TKAGFL
C514 WJ322300 C.CE.M.CHP 1000pF 630V TKAGFL
C515 WH035900 C.CE.SAFTY 1000pF 250V
C516-517 WK413800 C.CE.M.CHP 1000pF 250V
* C518-519 WQ081600 C.EL 2200uF 25V
C522 UR839100 C.EL 1000uF 16V
C523 UR848100 C.EL 100uF 25V
C524 WH138300 C.EL 1000uF 25V
P.C.B. MAIN and P.C.B. SUB
✻ New Parts ✻ New Parts
