Instrument and control functions
4-17
4
EAU13435
Catalytic converter
The exhaust system contains catalytic
converter(s) to reduce harmful exhaust
emissions.
EWA10863
The exhaust system is hot after op-
eration. To prevent a fire hazard or
burns:
Do not park the vehicle near
possible fire hazards such as
grass or other materials that
easily burn.
Park the vehicle in a place
where pedestrians or children
are not likely to touch the hot
exhaust system.
Make sure that the exhaust sys-
tem has cooled down before
doing any maintenance work.
Do not allow the engine to idle
more than a few minutes. Long
idling can cause a build-up of
heat.
EAU93101
Seats
Passenger seat
To remove the passenger seat
1. Insert the key into the seat lock,
and then turn it clockwise.
2. Lift the front of the passenger seat
and pull it forward.
To install the passenger seat
1. Insert the projection on the rear of
the passenger seat as shown.
2. Insert the key into the seat lock,
and then turn it clockwise. While
holding the key turned in the
clockwise position, push the front
of the seat down to lock it in place.
3. Remove the key.
Rider seat
To remove the rider seat
1. Remove the passenger seat, and
then remove the cover by remov-
ing the quick fasteners.
1. Seat lock
2. Unlock.
1. Projection
2. Seat holder
